32-channel embedded PoE network video recorder with 16 managed PoE ports, four 3.5-inch drive bays and 4K HDMI output. Built for scalable IP surveillance recording with H.265 support and RAID protection.
R16 593,41
Vivotek ND9542P 32 channel NVR provides centralised recording for IP surveillance installations, combining 16 integrated 802.3at/af PoE ports with support for up to 32 channels. Its four internal 3.5-inch drive bays and RAID 0, 1 and 5 options help support resilient, high-capacity video retention.
<h2>Vivotek ND9542P 32 Channel NVR Features</h2>
The Vivotek ND9542P 32 channel NVR supports H.265, H.264 and MJPEG video, with HDMI and VGA display outputs for local monitoring. Managed PoE, Smart VCA event search support and Deep Search capabilities make the Vivotek ND9542P 32 channel NVR suitable for professional security deployments.
Record and manage up to 32 IP camera channels from one embedded NVR.
Connect up to 16 PoE cameras directly through integrated 802.3at/af managed PoE ports.
Improve recording resilience with four internal HDD bays and RAID 0, 1 and 5 support.
| Model | ND9542P |
|---|---|
| Channels | 32 |
| Video compression | H.265, H.264, MJPEG |
| PoE ports | 16 x 802.3at/af managed PoE |
| PoE budget | 200 W maximum |
| Internal drive bays | 4 x 3.5-inch |
| RAID support | RAID 0, 1, 5 |
| Video outputs | 1 x HDMI, 1 x VGA |
| Maximum display resolution | 3840 x 2160 |
| Network interfaces | 2 x Gigabit Ethernet |
| Recording throughput | 192 Mbps |
| Dimensions | 432 x 421 x 66 mm |
| Weight | 4.6 kg without HDD |
