16-channel embedded PoE NVR with H.265 recording, four 3.5-inch HDD bays, 16 PoE ports and Deep Search support. Designed for scalable IP surveillance recording and monitoring.
R14 546,18
16 channel PoE NVR for professional IP surveillance deployments. The Vivotek ND9442P combines H.265 recording, 16 integrated 802.3at/af PoE ports and four internal 3.5-inch HDD bays in one embedded Linux recorder. HDMI and VGA outputs support local monitoring, while RAID 0, 1 and 5 options help protect recorded footage. ONVIF Profile S support assists with compatible camera integration.
## 16 channel PoE NVR for streamlined surveillance
Built-in 16-port PoE simplifies camera connections, with up to 200 W total PoE power.
Four 3.5-inch HDD bays and RAID 0, 1 or 5 support provide flexible recording storage and data protection.
Deep Search supports people, vehicle, scene and attribute searches when used with supported analytics cameras.
| Model | ND9442P |
|---|---|
| Channels | 16 |
| Video compression | H.265, H.264, MJPEG |
| PoE ports | 16 x 802.3at/af |
| PoE budget | 200 W maximum |
| Storage bays | 4 x 3.5-inch internal HDD bays |
| RAID | RAID 0, 1, 5 |
| Video outputs | 1 x HDMI, 1 x VGA |
| Network ports | 2 x Gigabit Ethernet |
| Camera integration | ONVIF Profile S |
| Recording throughput | 192 Mbps |
| Dimensions | 432 x 421 x 66 mm |
| Weight | 4.6 kg without HDD |
